| Application | Indoor |
| Type | Bar Primary/Ring/Rectangle Type |
| Casing | Polycarbonate |
| Highest Voltage for Equipment (kV) | 1.1kV |
| Rated Insulation Level (kV) | 1.1/4kVp |
| Rated Primary Current (A) | Up to 6000Amps |
| Rated Secondary Current(A) | 5A or 1A |
| Accuracy Class of Measuring Core | 0.2, 0.5, 1, 3, 5 |
| Instrument Safety Factor | <=5 (Depending on Accuracy Class) |
| Rated Burden of Measuring Core(VA) | Up to 30VA |
| Number of Cores | 1 |
| Rated Frequency (Hz) | 50/60Hz |
| Class of insulation | Class A, E and B |
| Applicable Standards | IS,IEC,ANSI,BS,etc. |
| Accessories | Mounting Clamp or Dinrail or Busbar Supportings |
