| Application | Indoor |
| Casting | Epoxy Resin/VPI |
| Highest Voltage For Equipment(Kv) | Up to 1.1 Kv |
| Rated Insulation Level(Kv) | 1.1 / 4kV |
| Rated Frequency(Hz) | 50-400Hz |
| No of Phases | Single Phase/Three Phase |
| Rated Primary Voltage(V) | Up to 1.1kV |
| Rated Secondary Voltage(V) | 110V/RT3,110V/3,110V(As Per Requirement) |
| Accuracy class | 0.1 to 3 |
| Rated Burden(VA) | Up to 500VA |
| Accuracy class of Protection core | 3P and 6P |
| Number of Windings | 1-2-3-4-5 |
| Class of insulation | Class B, F &H |
| Voltage Factor | 1.2 Continuous/1.5 for 30 sec,1.9 for 8 hours |
| Type of Earthing | One End Earthed Type(E‐N) / UN Earthed Type(U‐N) |
| Applicable Standards | IS,IEC,ANSI,BS,etc. |
